Properties.
Properties
Eco-friendly
Code: H108
Thickness: 16 mm
Order in the form of: pallet/sheet
Laminated: Glossy
Allowed range | Unit of measurement | Properties | |
0.4 | g/cm3 | density | 1 |
55 | Shore D | surface hardness | 2 |
2.5 > | Kg.mm-1 | screw | 3 |
12 | N.mm-2 | Tensile strength | 4 |
1 > | Kg.mm-1 | bending | 5 |
1 > | % | Water absorption | 6 |
3 | N.mm-1 | Compressive stress | 7 |
15 | KJ.m-2 | Impact resistance | 8 |
70 | ℃ | softening temperature | 9 |
14 | dB | sound conduction | 10 |
0.40 | W.mk-1 | Heat conduction | 11 |
B1 | class | Fire resistance | 12 |
112 | kV/cm | Dielectric power | 13 |
The specifications mentioned are related to grade A, 16mm Single Layer PVC Foam Boards and for other thicknesses, these numbers change according to the thickness and quality
One of the subsidiaries of Vispar Industrial Group, Unifoam was established in 2015 to produce polymer sheets. Unifoam is one of the leading manufacturers of PVC foam boards in Iran and Middle East. We produce Embossed, laminated and one layer PVC foam boards.
